Filter Press/Panel Cloths

Overview

Filter press cloths or filter panel cloths are specialized filter media used in filter press machines, which are widely employed across industries for solid-liquid separation. These cloths act as the primary barrier that captures solids while allowing clean filtrate to pass through, making them an essential component in industrial filtration systems.

At Filtech Textiles, we supply filter cloths to fit all standard plate sizes and also offer:

Types of Filter Media Used in Filter Press Cloths

MaterialMicron RatingAdvantagesLimitations
Polypropylene (PP)1 – 200 µmHigh chemical resistance, lightweight, economical, easy to cleanLimited temperature resistance (up to 90–110°C)
Polyester (PET)1 – 100 µm Good abrasion resistance, stronger than PP, handles higher temperature (up to 150°C)Less chemical resistance than PP
Polyamide (Nylon)10 – 100 µmExcellent mechanical strength, flexible, good for fine particlesLower resistance to acids and alkalis
Cotton20 – 100 µm Natural fiber, biodegradable, good for non-aggressive slurriesLow chemical and temperature resistance, short lifespan

Filter Cloth Weave Patterns

Choosing the right yarn design and weave pattern can significantly affect the filter cloth’s performance. We offer various designs and patterns to suit different operational needs:

Applications of Filter Press / Filter Panel Cloths
