Reverse Air Dust Collector Bags
Optimized for Gentle Cleaning Cycles and Maximum Filtration in Reverse Air Baghouse Systems
Overview
Reverse Air Dust Collector Bags are engineered for use in reverse air baghouse systems, where cleaning is done through a low-pressure reverse airflow that gently dislodges accumulated dust. These bags are typically longer and loosely fitted, designed to withstand extended cleaning cycles, high dust loads, and demanding industrial environments such as cement plants, power stations, and steel mills.
Reverse Air Baghouse Working Principle
Key Features
- Longer length construction (up to 8 meters) for high-volume systems
- Soft-cuff or raw end designs for easy clamping
- Compatible with low-pressure reverse air cleaning
- Surface treatments available: PTFE, antistatic, singeing, and glazing
- Built to handle high-temperature and abrasive conditions
Filter Media Specification for Pulse Jet Dust Collector Bags
| Parameter | Range / Details |
|---|---|
| Diameter Range | 120 mm to 300 mm |
| Length Options | 2000 mm to 8000 mm |
| Media Types | Polyester, Aramid (Nomex), Fiberglass, PPS, P84 |
| Temperature Resistance | Up to 260°C (based on media) |
| Top & Bottom Configurations | Soft Cuffs, Raw Edge, Corded Ends |
| Surface Finishes | Singeing, Glazing, PTFE Membrane, Anti-static, Water & Oil Repellent |
| Cleaning Mechanism Compatibility | Low-pressure reverse air baghouse systems |
| Filtration Efficiency | Up to 99.9% for fine and heavy dust |
| Industries Served | Cement, Power, Steel, Pulp & Paper, Fertilizers, Wood Processing |
Applications of Reverse Air Dust Collector Bags
- Cement kilns and clinker coolers
- Power generation and coal-fired boilers
- Steel production and sinter machines
- Chemical and fertilizer plants
- Wood processing and pulp manufacturing
⭐ Why Choose Filtech Textiles?
- Specialized in reverse air bags for long-cycle operations
- Expert tailoring for non-caged, soft-mount designs
- Durable fabric options tested for abrasive and high-temp dust
- Trusted supplier to major cement, power, and steel industries
